Long Life PVC Overlay Sheet Clean And Flatness Surface With Excellent Peeling Strength
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MCO-W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | by reel or 500 sheets per bag / 4-8 bags per paper carton , or as per customer requirements . All the cartons are firmly piled up and fixed on the solid plywood pallet |
| Delivery Time: | 10-15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 10 million square meters per month |
|
Detail Information |
|||
| Package Method: | 500 Sheets Per Bag / 4-8 Bags Per Paper Carton, Or By Reel, Or As Per Customer Requirements | Thickness: | 0.04，0.05，0.06，0.08，0.10mm Or Other |
|---|---|---|---|
| Color: | Transparent With One-side Glue Coating | Surface: | Clean And Flatness |
| Highlight: | pvc overlay film,film frame overlay |
||
Product Description
PVC Coated Overlay sheet special for PVC Sheets printed by offset or silkscreen printers for card production purpose
1. Brief Introduction of PVC Coated Overlay sheet special for PVC Sheets printed by offset or silkscreen printers for card production purpose
It is designed specially for laminating with the PVC sheet printed by various offset printers including Heidelburg and the silkscreen printing machine as well. Inkjet printer Ink. It can realize excellent peeling strength without deformation or color change after lamination.
2. Production Facilities for PVC Coated Overlay sheet special for PVC Sheets printed by offset or silkscreen printers for card production purpose
3. Techincal Description of PVC Coated Overlay sheet special for PVC Sheets printed by offset or silkscreen printers for card production purpose
● Suitable for lamination with the PVC sheets printed by various offset and inkjet printers
● Abrasion resistant , prolong the life of cards.
● Environment friendly in the card making process, no solvent or gas discharges.
| Item | Parameters | |
| Surface | Clean and flatness | |
| Dimensional Tolerance (mm) | ±1 | |
| Angle Cut Tolerance (mm) | ±1 | |
| Diagonal Difference (mm) | ≤1 | |
| Thickness Tolerance (mm) | ±10% | |
| Vicat (℃) | 72±2 | |
| Shrinkage | MD | ≥ - 40% |
| TD | ≤15% | |
| Tensile Strength (MPa) | MD | ≥35 |
| TD | ≥35 | |
Recommended Laminator parameters:
| Laminating Unit | Temp(℃) | Pressure(MPa) | Time (min) |
| Heat Laminating | 110~130 | ≥8 | 20 |
| Cool Laminating | ≤20 | ≥8 | 20 |
