5x5 Pvc Rfid Inlay / Prelam Sheets For Rfid Cards Production F1108 TK4168 Chip
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | 5x5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50000chips |
|---|---|
| Price: | based on the layout and order qty |
| Packaging Details: | By carton |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 chips per week |
|
Detail Information |
|||
| Material: | PVC | INLAY Size: | 310x460mm Or According To Customer's Request |
|---|---|---|---|
| Application: | For RFID Card Production | Product Name: | RFID Inlay Prelam |
| Thickness: | 0.45-0.50mm | Surface: | Trimming And Position Border |
| Highlight: | 5x5 pvc rfid inlay,rfid cards production pvc rfid inlay,F1108 TK4168 chip prelam sheets |
||
Product Description
5x5 PVC RFID Inlay/Prelam sheets for RFID cards production F1108 TK4168 chip
1. RFID Inlay/Prelam sheets for RFID cards production- IC Fudad F08 chip-Description
Material: 0.5mm thick card core material, including low -frequency core steps (125kHz), high -frequency chip (13.56MHz)
Chip models: EM4100, EM4102, SMC4001, T5567, F1108 TK41681S70, Ultralight10, ESFIRE41F1108 TK41681S50, F1108 TK41682, F1108 TK41681, etc.
Chip specifications: 8 -installed core materials, 10 core materials, 20 core materials, 21 core materials, 24 core materials, 25 core materials, 32 core materials (number of core materials per large version)
Production method: hot layer pressure, use PVC or PET material
2. RFID Inlay/Prelam sheets for RFID cards production-A3 IC Fudad F08 chip- Futures
We can supply you the real quality RFID card INLAY/PRELAM sheets with competitive factory prices.
Product key features:
Sheet Layout: 2X5, 3X7, 3X8, 5X5, 4X8 or customized
Material: PVC
Sheet thickness: 0.45-0.5mm or customized.
Chip types:
125 KHz LF chips:
ID4168/TK4100/TSS77/compatible chip1/compatible chip2/compatible chip S256/compatible chip 2048/relevant more
13.56MHz HF chips:
Fudan FM11RF08/ Feiji-F8001/ISSI4439/Fudan-FM11RF32/S50/S70/Ultralight/F1108 TK4168/Natag…
Antenna: copper wire
3. RFID Inlay/Prelam sheets for RFID cards production-A3 IC Fudad F08 chip-Usage
Application: Suitable for smart card manufacturers to use directly
