0.50mm Low Vicat Offset Printable Pvc Core Sheet
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MCS-SIM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 100 or 200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets |
| Delivery Time: | 10-15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10-15 million square meters per month |
|
Detail Information |
|||
| Thickness: | 0.10 - 0.50mm | Surface Roughness: | 0.7~1.8 μm |
|---|---|---|---|
| Thickness Tolerance %: | ±5 | Squareness Mm: | ±1 |
| Size: | A4 , A3 Or Customized | Vicat ℃: | 77±2 |
| Highlight: | 0.50mm Pvc Core Sheet,Low Vicat Pvc Core Sheet,SIM Card Body Production Sheet |
||
Product Description
Offset printable PVC white core sheet / PVC Base Sheet Special for SIM Card Body Production
Product Technical Specification
| 1. Introduction of Offset printable PVC white core sheet / PVC Base Sheet Special for SIM Card Body Production |
PVC sheet for SIM Card Production (also named as PVC SIM Card Base or PVC Sheet for mobile SIM Card production) is mainly used as the special sheet materials for production phone SIM cards. Such material is featuring as high heat resistance as well as the higher fire resistance (above FH-1).
Characteristic:
1). Excellent stable quality
2). Special formulation according to each client's requirement
3). Exact sheet size cutting and thickness control
4). Low dust
5). Surface tension can over 40 Dyne
6). Low static easy for sheet feeding
7). Smooth roughness
8). Adjustable VICAT degree
9). Adjustable Opaque degree
10). Less than15 days Short Lead Time
11). Perfect packaging for transportation
12). Best after sell service
| 2.Specification of Offset printable PVC white core sheet / PVC Base Sheet Special for SIM Card Body Production |
Thickness Range: 120 ~ 760 Micron
Color: White, Transparent or Colored
Size: Sheet size or roll size
Roughness: Both sides matte
Vicat point: 77+2 ℃ (ISO306B50)
Width: <=1530mm
Inner Core Diameter: 3’’(76mm)
| Item | Unit | Value | |
| Density | g/cm3 | 1.29 ±0.05 | |
| Tensile Strength | Horizontal | MPa | ≥45 |
| Vertical | ≥48 | ||
| Vicat 5kg | ℃ | 90±2 | |
| Surface Roughness | Ra | μm | 0.7~1.8 |
| Rz | 5.0~10.0 | ||
| Surface Dyne | dynes/cm | 4#≥34, 5#≥36 | |
*Customized design is availalbe.
| 3. Applications of Offset printable PVC white core sheet / PVC Base Sheet Special for SIM Card Body Production |
PVC Sheet for SIM Card Production is mainly used for making GSM SIM Card. Such material is specially designed to meet the special SIM CARD functional requirements such as high heat resistance and fire resistance.
Applicable:
Our PVC sheet can be made Bank card, Credit card, Membership card, SIM card and so on.
Usage:
It can make laminated or un-laminated cards, can be printed, coated, jetted with all colors, punched.
| 4. Packging and storage of Offset printable PVC white core sheet / PVC Base Sheet Special for SIM Card Body Production |
Offset printing sheets MOP series are designed for offset printer and silk screen printer use. They can also be used as non-printed middle core sheet. They are massively used by many card factories worldwide.
1) Suitable for the whole series of offset printer and silk screen printer.
2) High definition images.
3) Excellent ink adhesion with strong peeling strength after lamination.
4) No crack occurs on the printed images after lamination at high temperature.
