A3 Size 0.76mm Silk Screen Printing PVC Core Sheet
Product Details:
| Place of Origin: | China |
| Brand Name: | MK |
| Model Number: | MOP-W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20000 sheets or 2 tons |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 100 or 200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets |
| Delivery Time: | 10-15 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10-15 million square meters per month |
|
Detail Information |
|||
| Thickness Range: | 100micron - 850micron | Popular Size: | 210*297mm Or 300*297mm Or Customized |
|---|---|---|---|
| Common Color: | Common White/ Super White | Suitable Printer Models: | The Whole Series Of Offset Printer And Silk-screen Printers |
| Storage Condition: | Sealed, Moisture-proof, Room Temperature Under 40℃ | Package Method: | 100-200 Sheets Per PE Bag, All The Bags Are Firmly Piled Up And Fixed On The Solid Plywood Pallets |
| Highlight: | A3 PVC Core Sheet,0.76mm PVC Core Sheet,Silk Screen Printing PVC Core Sheet |
||
Product Description
A3 Size 0.76mm Smart Card Material PVC Core Sheet Silk Screen Printing
1. Technical Data of A3 Size 0.76mm Smart Card Material PVC Core Sheet Silk Screen Printing
Offset printing sheets MOP series are designed for offset printer and silk screen printer use. They can also be used as non-printed middle core sheet. They are massively used by many card factories worldwide.
1) Suitable for the whole series of offset printer and silk screen printer.
2) High definition images.
3) Excellent ink adhesion with strong peeling strength after lamination.
4) No crack occurs on the printed images after lamination at high temperature.
Technical parameters:
| Item | Index | |
| Tensile strength | Longitudinal MPa | ≥45 |
| Transverse MPa | ≥40 | |
| Vicat ℃ | 77±2 | |
| Surface Tension dyne/cm | ≥35 | |
| Heat shrinkage rate% 140℃ 10min | Transverse ≤5 | |
| Longitudinal ≥-10 | ||
| Squareness mm | ±1 | |
| Thickness tolerance % | ±5 | |
| Roughness μm | Ra,μm | 0.7~1.4 |
| Rz,μm | 4~9 | |
2. Features of A3 Size 0.76mm Smart Card Material PVC Core Sheet Silk Screen Printing
1). Low dust
2). Excellent stable quality
3). Exact sheet size cutting and thickness control
4). Low static easy for sheet feeding
5). Smooth roughness
6). Adjustable VICAT degree
7). Adjustable Opaque degree
8). Perfect packaging for transportation
9). Special formulation according to each client's requirement
10). Surface tension can over 40 Dyne
11). Less than15 days Short Lead Time
12). Best after sell service
| Item | Unit | Value | |
| Density | g/cm3 | 1.42±0.05 | |
|
Tensile Strength |
Horizontal |
MPa |
≥44 |
| Vertical | ≥46 | ||
| Vicat 5kg | ℃ | 80±2 | |
|
Surface Roughness |
Ra |
μm |
0.7~1.8 |
| Rz | 4.0~12.0 | ||
| Surface Dyne | dynes/cm | ≥34 | |
*Customized design is availalbe.
3. Application of A3 Size 0.76mm Smart Card Material PVC Core Sheet Silk Screen Printing
Our PVC sheet can be made Bank card, Credit card, Membership card, SIM card and so on.
It can make laminated or un-laminated cards, can be printed, coated, jetted with all colors, punched.
